Altronix → Altronix ALTV1224DC1220 12/24vdc/4a/16 out cctv p/s 22
Altronix  ALTV1224DC1220
rganization

Altronix ALTV1224DC1220 12/24vdc/4a/16 out cctv p/s 22

Special Price: $138.77
SKU: AX-1224DC122
LimitedAvailability
MPN: ALTV1224DC1220
Email this product to a friend
  • Description
  • Reviews
ALTV1224DC1220

CCTV Power Supply, 16 Fused Outputs, 12/24VDC @ 4A, 220VAC, BC300 Enclosure

ALTV1224DC1220 is designed to power CCTV Cameras and accessories. It provides 12VDC or 24VDC distributed via sixteen (16) fuse protected outputs with a total of 4A total supply current.

Input
Input 220VAC (working range 198VAC-256VAC), 50/60 Hz, 0.6A.
Output
Sixteen (16) fuse protected outputs.
12VDC or 24VDC.
4A total continuous supply current (0.25A per device, 3.5A max.).
Outputs are rated @ 3.5A.
Filtered and electronically regulated outputs.
Electrical
Temperature:
Operating: 0 ° C to 49 ° C (32 ° F to 120 ° F).
Storage: - 20 ° C to 70 ° C ( - 4 ° F to 158 ° F).
Relative Humidity 85% +/- 5%.
BTU/Hr (approx.):
12VDC: 25 BTU/Hr.
24VDC: 49 BTU/Hr.
System AC input VA requirement: 176VA.
Features
AC input and DC output LED indicators.
Power ON/OFF switch.
Unit maintains camera synchronization.
Ease of installation saves time and eliminates costly labor.
